Car Aroma Diffuser AP C500B
The AP C500B Car Aroma Diffusers are compact, rechargeable scenting devices designed for in vehicle use, offering efficient fragrance dispersion in spaces up to 6 m². Built with lightweight PP and glass materials, each unit features a 5 ml refillable bottle, USB charging interface, and vibration sensing technology that activates misting only when motion is detected. Users can select between two diffusion grades—L1 (purple) and L2 (blue)—with misting intervals of 5 seconds followed by pause cycles of 10 or 5 minutes respectively. The devices include ambient lighting, intuitive one button control, and safety features such as auto shutdown, spill prevention, and charging protection. Installation is simple using the provided cotton sticks, clip, and adhesive backing, while regular maintenance ensures optimal performance. These diffusers are ideal for personal vehicles, offering quiet operation, portability, and a refined fragrance experience tailored for mobile environments.
Product Specifications
| Feature | Details |
|---|---|
| Model | AP C500B |
| Size | 94 * 26 * 31mm |
| New Weight | 50g |
| Battery Capacity | 300mAh |
| Voltage/Power | 5V / 1W |
| Bottle Capacity | 5ml |
| Coverage | Up to 6m³ / 210ft³ |
| Materials | PP (Machine shell) + Glass (Bottle) |
Installation Guide
Step 1:
open: Pull the nebulizing part (top) upwards to remove it from the base.
Step 2:
Assemble: Unscrew the bottle cap, insert the cotton core vertically into the bottle, and then screw the diffuser head onto the bottle.
Step 3:
Tighten: Screw the bottle clockwise until it is securely attached.
Step 4:
Close: Slide the nebulizing part back down onto the base.
Step 5:
Ready: Press the power button to start.
Operation Guide
-
Power On/Off
Long press the button.
-
Switch Levels
Short press the button to toggle between misting modes
-
Charging Indicators
Red Light: Charging in progress.
Blue Light: Fully charged. -
Charging Indicators
1- The device features a built-in vibration sensor. It works when it senses movement (car driving).
2- If no vibration is detected for 60 seconds, the device automatically enters "Sleep Mode" to save power and fragrance.
Important Cautions & Maintenance
Keep Vertical
Always keep the machine in a vertical position. Tilting or lying it down may cause oil leakage and damage the circuit board.
Charging
Use a standard USB cable. Do NOT use quick chargers, as they may damage the battery.
Charging Time
A full charge of 3.5 hours is highly recommended.
Fragrance
Only use the matched formula fragrance provided. Using other oils may clog or damage the machine.
Transporting
If you are carrying the machine outside the car, remove the fragrance bottle and keep it capped.
Do Not Disassemble
Do not attempt to repair or modify the machine yourself.
Mist Modes (Grade Indication)
| Grade | Indicator Color | Working Interval |
|---|---|---|
| L1 | Purple | Mists for 5s, pauses for 10 mins |
| L2 | Blue | Mists for 5s, pauses for 5 mins |
What’s in the Box?
• 1x Diffuser Machine
• 1x Fragrance Bottle
• 8x Cotton Sticks (including backups)
• 1x Mounting Sticker & Clip
• 1x Charging Cable
• 1x User Manual
For further assistance or to purchase replacement fragrance bottles, please contact our customer service team.
