AP H700B Smart Bluetooth Aroma Diffuser | 2025 Upgraded Professional Scenting System
The AP H700B Aroma Diffuser is a compact, Bluetooth enabled scenting device designed for efficient fragrance distribution in spaces up to 30 m². Equipped with a 60 ml refillable bottle and three adjustable atomization grades, it delivers consistent diffusion with low power consumption. Through the Scent Marketing app, users can customize working periods, set weekly schedules, adjust spray and pause times, and manage device settings with secure password protection. The diffuser features multiple operating modes, including 3 hour, 6 hour, and Smart Bluetooth mode, with clear LED indicators and audible buzzer feedback for each operation. Its straightforward installation, durable construction, and recommended maintenance procedures ensure stable long term performance, while built in safety guidelines, FCC/ISED compliance, and troubleshooting support make it suitable for professional environments requiring reliable scent management.
Key Features
Bluetooth App Integration
Seamlessly control your environment via the "Scent Marketing" app (iOS/Android). Set schedules, adjust intensity, and monitor status from your smartphone.
2025 Advanced Nebulization
Unlike traditional diffusers, the AP H700B uses cold-air atomization to turn essential oils into a dry mist without water, preserving the therapeutic properties of your oils.
Dual-Control Interface
Manage the device via the intuitive physical buttons or the smart app for ultimate flexibility.
Intelligent Scheduling
Feature-rich timer functions including 3-hour and 6-hour cycles, or fully customizable "Working Periods" via the app.
Whisper-Quiet Efficiency
Consuming only 1.5W, it provides powerful scenting with minimal energy impact and silent operation.
Technical Specifications
| Parameter | Technical Detail |
|---|---|
| Model | AP H700B (2025 Upgraded Edition) |
| Connectivity | Bluetooth (App Controlled) |
| Bottle Capacity | 60ml |
| Dimensions | 110mm * 101mm * 60mm |
| Coverage Area | 30m² / 90m³ / 3100ft³ |
| Power Consumption | 1.5W |
| Input Voltage | AC 100V-240V 50/60Hz |
| Net Weight | 0.28kg |
Smart Operating Modes & Customization
1. Manual Timer Modes
• 3H Mode: Runs for 3 hours (Blue light), then enters a 21-hour standby (Yellow light).
• 6H Mode: Runs for 6 hours (Blue light), then enters an 18-hour standby (Yellow light).
2. Intensity Levels (Grades)
| Grade | Work Time (s) | Stop Time (s) | Oil Consumption |
|---|---|---|---|
| G1 (Low) | 15s | 120s | 0.18g/h |
| G2 (Medium) | 15s | 90s | 0.24g/h |
| G3 (High) | 15s | 60s | 0.30g/h |
Bluetooth App Setup (Scent Marketing)
Search for "Scent Marketing" on the App Store or Google Play.
Open the app, select Bluetooth, and pick your device (AP H700B).
Enter the default factory password: 8888.
Set specific "Start" and "Stop" times for every day of the week and define custom spray/pause intervals.
Installation & Maintenance
Quick Setup:
Step 1:
Lift the diffuser head and bottle upward to remove.
Step 2:
Unscrew the bottle and fill with high-quality essential oil (No water required).
Step 3:
Tighten the bottle back onto the head and align it into the machine.
Step 4:
Press downward until securely seated.
Professional Maintenance
• Fill the bottle with a small amount of industrial alcohol.
• Soak the atomizing head for 5-10 minutes.
• Run the device for 5 minutes with alcohol to clear any oil residue.
Important Safety Guidelines
-
Vertical Operation Only
The machine must remain upright. Tilting or laying the machine flat will cause oil leakage and permanent damage to the internal air pump.
-
Pure Oil Only
Use essential oils with a viscosity below 30mPa.s for the best diffusion effect.
-
Transportation
Always empty the oil bottle before shipping or moving the device.
Troubleshooting
- 1 No Diffusion Check if the app is in a "Non-Working Period" or if the air pump is damaged.
- 2 Weak Mist Clean the atomizing core with alcohol; check if the gasket is missing or loose.
- 3 Abnormal Noise Ensure the air pump is tightened or check for internal loose parts.
