AP H710B Smart Aroma Diffuser: Premium Scenting Redefined
The AP H710B Aroma Diffuser is a high efficiency, Bluetooth enabled scenting device designed for medium to large spaces up to 100 m². Built with a durable aluminum body and a 120 ml refillable bottle, it operates on a stable 12V/2A power supply and includes a 2200 mAh lithium battery for flexible placement. The diffuser offers five preset intensity grades plus a customizable mode, multiple timer options (1H, 2H, 4H, 8H, Smart, and 24H), and an ambient light feature that can function independently as a night light. Through the Scent Marketing mobile app, users can set detailed working schedules, adjust spray and pause times, calibrate oil consumption, and manage device settings with secure password protection. The unit features an LCD screen, auto lock safety, and clear indicator lights for Bluetooth status and battery level. Routine alcohol based cleaning and straightforward troubleshooting ensure reliable long term performance in professional environments such as hotels, retail stores, offices, and wellness spaces.
Premium Aluminum Construction
The device is crafted from high-quality aluminum, providing a sleek, modern aesthetic and exceptional durability compared to plastic diffusers.
Dual Control Modes (BT + Button)
It offers versatile operation through two methods: physical touch buttons on the device for quick adjustments and a dedicated "Scent Marketing" App via Bluetooth for advanced settings.
Rechargeable Battery & Portability
Equipped with a 2200mAh lithium battery, the diffuser is fully portable. This allows you to place it anywhere in your home or office without being restricted by the location of power outlets.
Large Coverage Area
Despite its compact size, the device is powerful enough to cover up to 100m² (300m³ / 10,500ft³), making it suitable for large living rooms, offices, or commercial spaces.
Customizable Intensity Levels
The diffuser features 5 preset intensity grades plus a "Custom" mode. In custom mode, users can precisely set the "Spray Time" and "Pause Time" (in seconds) to perfectly match their preference and save essential oil.
Intelligent Scheduling & Timer
Through the app, users can set specific working periods for different days of the week (e.g., auto-start at 9:00 AM and stop at 5:00 PM). Additionally, the device has built-in timer options for 1H, 2H, 4H, and 8H cycles.
Technical Specifications
| Feature | Details |
|---|---|
| Material | Premium Aluminum |
| Coverage | 100㎡ / 300m³ / 10500ft³ |
| Battery | 2200mAh Li-battery (Rechargeable) |
| Input | 12V 2A (Power adapter included) |
| Bottle Capacity | 120ml |
| Size | 117.5*117.5*342mm |
Product Support: Model AP H710B Smart Aroma Diffuser
Welcome to the support page for the Model AP H710B Aroma Diffuser. This premium aluminum diffuser combines advanced atomization technology with smart Bluetooth control to create the perfect ambiance for your space.
Quick Start Guide: Installation
Setting up your AP H710B is simple. Follow these four steps:
1- Remove the Head:
Gently lift the diffuser head out of the main body.
2- Detach the Bottle:
Twist the 120ml essential oil bottle clockwise to remove it.
3- Fill:
Fill: Fill the bottle with your favorite high-quality essential oil.
4- Assemble:
Screw the bottle back onto the head securely and reinsert the head into the machine.
Smart App Setup ("Scent Marketing")
To unlock full scheduling and customization features, use the dedicated app.
1- Download:
Search for "Scent Marketing" on the Google Play Store or Apple App Store.
2- Connection:
Ensure your phone’s Bluetooth and Location services are enabled.
3- Initial Login:
Select your device (A326_XXXX). The default factory password is 8888.
4- Features:
Within the app, you can set "Start" and "Stop" times, choose specific days of the week, and calibrate oil consumption.
Manual Controls & Functional Analysis
If you prefer manual operation, use the touch-sensitive icons on the device:
1- Power (ON/OFF):
Short press to toggle power. Long press for 5 seconds to restore factory settings (resets levels, programs, and passwords).
2- Grade Button:
Short press to cycle through intensity levels: Grade 1 → 2 → 3 → 4 → 5 → Custom.
3- Ambient Light:
Press the light icon to toggle the night light on or off.
4- Timer:
Press to switch between operation modes: 1H, 2H, 4H, 8H, Smart, or 24H (default).
Concentration & Battery Life
| Grade | Work time(s) | Stop time(s) | Battery life(H) | Consumption(g/h) |
|---|---|---|---|---|
| G1 | 5s | 240s | 200H | 0.05 |
| G2 | 15s | 200s | 80H | 0.17 |
| G3 | 20s | 160s | 50H | 0.27 |
| G4 | 25s | 100s | 29H | 0.49 |
| G5 | 25s | 60s | 20H | 0.72 |
| Customized | 5-35s | 60-300s | - | - |
- Note: For best results, use essential oils with a viscosity below 30mPa.s.
Maintenance & Cleaning
To ensure the longevity of your diffuser, clean the unit when changing scents or if the mist becomes weak.
step 1:
Fill an empty bottle with industrial alcohol.
step 2:
Run the machine for 5–10 minutes to flush the atomizing core.
step 3:
Wipe the nozzle area to prevent oil buildup.
Troubleshooting
| Issue | Potential Solution |
|---|---|
| No Diffusion | Check if the power is ON. If the pump is running but no mist appears, clean the core with alcohol. |
| Weak Diffusion | The atomizing core may be blocked, or the straw may be loose. Replace the atomized core if cleaning fails. |
| Oil Leakage | Ensure the bottle is screwed in tight and the machine is kept vertical. Never tilt or lay the machine flat. |
| Abnormal Sound | The air pump may be loose. Contact support if the noise persists after tightening. |
- Safety Warning: Always keep the machine in a vertical position. Tilting the device can cause oil to overflow into the circuit board, leading to permanent damage.
